Day 1 | 22 October
This agenda is for the Perovskite Connect talks and is a part of the full conference agenda
Track 1
Perovskite Keynotes - Track 2-3
Oxford PV
The world's first commercial tandem perovskite-silicon module
9:10 AM
Edward Crossland
Today’s mainstream solar photovoltaic technology – silicon – is nearing its practical and economic efficiency limits. Perovskite-silicon tandem technology breaks through this efficiency barrier to deliver the highest-efficiency, most versatile, space and cost-effective type of solar cell in the world. As the next generation of solar PV, this innovation has the potential to transform the economics and accelerate the growth of solar generation applications globally. In 2024, Oxford PV marked a historic milestone by shipping the world’s first commercial perovskite-silicon tandem modules, demonstrating that this breakthrough technology is now commercially viable and ready for large-scale deployment.
This presentation will explore the rapid development and exceptional performance of perovskite-silicon tandems, highlighting recent advancements and charting the roadmap to further improvements. Key challenges such as ensuring long-term durability, scalability, and meeting rigorous environmental standards will be described alongside innovative solutions in processing, materials science, and device architectures to overcome them. A particular emphasis will be placed on scaling and manufacturability, demonstrating how the perovskite cell technology can integrate into existing silicon cell manufacturing process flows and product designs with minimal disruption. Insights from Oxford PV R&D, pilot, production and collaborative industrial initiatives will showcase the readiness of this technology for commercial deployment.
This presentation will provide a vision for how this groundbreaking technology will help drive the next phase of solar energy adoption, shaping a cleaner and more sustainable future.
Hangzhou Microquanta Semiconductor Co., Ltd.
Bridging the Gap: The Commercial Readiness of Perovskite PV
9:30 AM
Yang Chen
Perovskite photovoltaics have shown remarkable potential in the laboratory, but the path to commercial viability has demanded solutions to persistent challenges in stability, efficiency, and scalable manufacturing. This presentation outlines our journey in addressing these hurdles—ranging from material degradation and device architecture to module production and international certification.
By sharing lessons learned through real-world deployment and industrial validation, this talk offers a grounded technical perspective on how perovskite PV is evolving into a commercially ready solar technology—poised not only to complement, but to surpass traditional silicon in key applications.
Swift Solar
Unlocking the Potential of Perovskite-Silicon Tandem PV: Insights into the Journey from Lab to Fab
9:50 AM
Maximilian Hoerantner
As the balance-of-system costs rise within photovoltaic (PV) installations, achieving higher power conversion efficiency (PCE) has become critical for further reductions in overall PV system costs. With crystalline silicon technology approaching its practical efficiency limits, tandem architectures—particularly perovskite-silicon tandems—are emerging as the next major leap in solar cell performance. Perovskites offer a unique combination of high performance, tunable bandgap, and low-cost processing, enabling these tandems to significantly surpass the efficiency ceiling of single-junction c-Si cells.
However, the pathway to commercializing perovskite-Si tandem technology extends beyond incremental PCE improvements. Key challenges remain, including long-term stability, large-scale manufacturability, reproducibility, and high-throughput production. We are tackling these challenges through a comprehensive approach: optimizing device performance, enhancing perovskite heat and light stability, and simultaneously scaling up processes to accommodate commercial wafer sizes.
Our efforts are focused on developing high-throughput manufacturing techniques and improving process reliability to achieve consistently high yields. This work is essential for making perovskite tandems a truly viable and scalable solution for future solar energy needs. In this presentation, we will share our latest progress in advancing tandem PV technology, with particular emphasis on the rapid development of robust, scalable device stacks and the reliability of our materials and processes.
We will also highlight our expanded testing infrastructure, designed to evaluate large volumes of devices over extended durations, and present results from experimental studies conducted under stringent light and thermal stress conditions. Coupled with computational modeling and simulation, these data provide valuable insights into the predicted operational stability and performance of our perovskite products across diverse geographical environments.
Solar and Renewable Industry Leader
The future of European solar manufacturing: niche only or mass production?
10:10 AM
Gunter Erfurt
Break
10:30 AM
--------------------------------
Exhibition & Refreshment Break
10.30AM
Perovskite - Track 1
Track 2
Track 3
Track 4
University of Rome Tor Vergata
Scalable and Ambient-Air Processing of Printed Perovskite Modules
11:15 AM
Luigi Vesce
Scalable and Ambient-Air Processing of Printed Perovskite Modules
11:15 AM
Beyond Silicon, Inc.
Manufacturable Perovskite/Silicon Tandems with Solution-Processing
11:35 AM
Mathilde Fievez
Manufacturable Perovskite/Silicon Tandems with Solution-Processing
11:35 AM
Solaires Entreprises Inc
From Lab to Fab: Navigating the Challenges and Lessons Learned in Scaling Perovskite PV Modules
11:55 AM
Sahar Sam
Perovskite photovoltaics (PVs) are a rapidly advancing solar technology with the potential to be a cost-effective, high-performance solar technology where the lab results show remarkable progress, with material properties indicating strong potential for both indoor and outdoor applications. However, transitioning from small, controlled lab devices to large-area, industrially relevant modules for mass production presents significant technical and manufacturing challenges.
The presentation will explore these critical barriers to the commercial viability of perovskite PV technology. We will share insights from our pilot-scale fabrication efforts using scalable deposition techniques like slot-die and blade coating, which are promising for high-throughput, low-cost manufacturing of large-area perovskite films. Our discussion will cover the practical challenges of implementing these techniques, including coating optimizations, interface compatibility issues and the module fabrication in general. We will also detail the necessary process integration and modifications at each stage of module fabrication for seamless and efficient manufacturing. Furthermore, we will highlight the valuable feedback obtained from pre-commercial validation efforts conducted with industry partners on the performance and reliability of our large-area perovskite modules under more realistic conditions.
By connecting fundamental laboratory research with the practicalities of large-scale manufacturing, this talk aims to provide a comprehensive roadmap for overcoming current obstacles to the widespread commercialization of perovskite PV technology. Our experiences emphasize the crucial need for a multidisciplinary and collaborative approach involving researchers, engineers, material scientists, and industry partners to effectively tackle the diverse challenges facing perovskite technology on its path to market.
From Lab to Fab: Navigating the Challenges and Lessons Learned in Scaling Perovskite PV Modules
11:55 AM
Institut Photovoltaïque d’Île-de-France (IPVF)
IPVF pilot line: a testbed for development & testing of perovskite solar cells & modules.
12:15 PM
Michel Kochanski
After decades of research and development, commercial Si solar cells are nearing their fundamental limit in terms of power conversion efficiency. To bypass this limit and further
decrease the cost of solar electricity, one promising path is to complement Si with an additional light absorber to use the incoming light more effectively. Metal halide
perovskites, with exceptional optoelectronic performance, are one of the prominent
candidates for such a combination. After several years of research, the IPVF has developed manufacturing processes that are ready for industrialization.
To this end, IPVF is building a lab2fab perovskite pilot line in Paris-Saclay. At the end of
2025, it will be opened to companies wishing to develop perovskite cells and modules with different substrates or encapsulants, or to test different precursors. What's more, the IPVF also boasts top-level testing facilities and scientific expertise to analyze materials and qualify the potential of photovotlaictechnologies. Our technology platform serves extended applications in thin films development, material engineering, photonics, semiconductors...
Presented by Nicolas VANDAMME, Integration and Prototyping Platform Manager at Institut Photovoltaïque d'Ile-de-France (IPVF) Company description IPVF - Institut Photovoltaïque d’Île-de-France, is a global Research, Innovation and
Education center, which mission is to accelerate energy transition through science & technology.
Gathering industrial PV leaders (EDF, TotalEnergies, Air Liquide, Horiba and Riber) and world-renowned academic research teams (CNRS, Ecole Polytechnique), multi- disciplinary and international IPVF teams conduct research for clean energy technologies. Supported by the French State, IPVF is labelled Institute for Energy
Transition (ITE).
IPVF pilot line: a testbed for development & testing of perovskite solar cells & modules.
12:15 PM
Track 1
Track 2
Track 3
Perovskite - Track 4
Sofab Inks
2:05 PM
Novel materials for next-generation perovskite solar panel production processes
Blake Martin
As the solar industry pushes toward large-scale production, both efficiency and scalable manufacturing must be prioritized. However, the current challenge lies in identifying materials that not only perform well but also scale effectively for mass production. This talk will explore certain materials that can bridge this gap, offering a solution that balances performance and manufacturability, and addressing key material challenges for perovskite solar cells at scale using soluble processes
Novel materials for next-generation perovskite solar panel production processes
2:05 PM
Karlsruhe Institute of Technology
2:25 PM
New Materials for Metallization and Interconnection of Perovskite Cells: Low-Temperature Processing & Reduced Silver Consumption
Norbert Willenbacher
The goal of significantly reducing CO2 emissions requires a massive expansion of PV installations worldwide. Perovskite cells offer a unique opportunity to enable this at a low consumption of precious resources and energy. This requires metallization and interconnection materials that can be processed at low temperatures. In order to avoid bottlenecks in the supply of silver for contacting and inter-connection of solar cells, the specific silver consumption in the production of solar cells and PV modules must be constantly reduced. The capillary suspension phenomenon (Koos and Willenbacher, Science 331, 897 2011) provides a unique opportunity to design printable pastes and adhesives with high electrical conductivity at low silver consumption. The addition of a second immiscible liquid to a suspension of particles leads to the self-assembly of a strong particle network controlled by capillary forces in such ternary solid/fluid/fluid systems. This results in a drastic change of texture and flow behavior, but also reduces the percolation threshold leading to a high electrical conductivity at low volumetric particle loading in composites including conductive fillers such as silver particles. Pastes for the metallization of temperature-sensitive Perovskite solar cells are sintered at low temperature (< 150°C) and include polymeric additives to provide cohesion of printed finger lines and sufficient adhesion to the transparent conductive oxide (TCO) surface layer. The required polymer content can be reduced and the surface properties of the conductive particles in the contact areas can be designed in such a way that high electrical conductivity and low contact resistance are achieved.
The TECC wire concept uses round copper wires for cell interconnection. These wires are coated with a thermoplastic polymer filled with conductive particles. The polymer ensures good mechanical adhesion to the cell surface and the conductive particles enable low contact resistance. Good interconnection at gentle processing conditions in terms of pressure and temperature has been achieved using thermoplastics with low silver content. Thermoplastic busbars (patent pending) is a recently developed concept further simplifying cell interconnection and reducing resource usage. Electrically conductive, thermoplastic materials melting at low temperature are applied in the metallization process and untreated copper wires are applied in a fast, low temperature stringing process. The capillary suspension concept has been utilized first to design printable, electrically conductive materials including silver particles but the transfer of the concept to composites including other conductive particles such as copper and silver coated copper or glass particles is straight forward.
New Materials for Metallization and Interconnection of Perovskite Cells: Low-Temperature Processing & Reduced Silver Consumption
2:25 PM
Nano-C, Inc.
2:45 PM
Innovative Interface Materials for Perovskite Photovoltaics
Henning Richter
Suitable interface materials are highly critical for single-junction but also tandem Perovskite photovoltaics both in terms of power conversion efficiency and, particularly, stability. Using its long experience with fullerenes and fullerene derivatives addressing improved performance of organic photovoltaic devices as starting point, Nano-C has developed a range of new generation electron transporting interface materials allowing for passivation and prevention of delamination. C60 or C70 fullerenes bearing suitable functional groups such as phosphonic, carboxylic or ammonium chloride/iodide allow for the stabilization of the Perovskite phase and adhesion on the adjacent metal oxide layers. Electronic properties can be adjusted for optimized band alignment depending on the specific Perovskite phase used. Molecules synthesized by Nano-C will be described and use cases discussed. The industrial scale manufacturing of fullerenes and new generation fullerene derivatives intended to accelerate the commercial deployment of Perovskite technology will be presented.
Innovative Interface Materials for Perovskite Photovoltaics
2:45 PM
DELO Industrial Adhesives
3:05 PM
Pioneering the Future: DELO's Advanced Adhesives Enhance Perovskite Solar Cell Protection
Sebastian Stasch
High-barrier encapsulants are essential for the protection of perovskite solar cells, acting as a shield against moisture that can cause degradation. These encapsulants create a strong, flexible seal that enhances the cells' durability, longevity, and efficiency. DELO, renowned for its barrier adhesives in organic solar cells, is leveraging its expertise to develop new adhesive solutions specifically designed for perovskite solar cells. This talk will provide insights into DELO's current advancements in this field, highlighting how these new adhesives are tailored to meet the unique challenges of perovskite technology, ensuring improved stability and performance.
Pioneering the Future: DELO's Advanced Adhesives Enhance Perovskite Solar Cell Protection
3:05 PM
Break
3:25 PM
Exhibition & Refreshment Break
--------------------------------
Exhibition & Refreshment Break
3:25 PM
Track 1
Track 2
Perovskite - Track 3
Track 4
Halocell Energy
Path to Commercializating Roll-to-roll Lightweight Flexible Perovskite Solar Modules.
4:10 PM
Tom Fontaine
Since their introduction in 2009, perovskite photovoltaics have rapidly advanced, achieving power conversion efficiencies of 26.7% under standard solar illumination and over 44% under low-intensity indoor lighting. Despite improvements in efficiency, stability, and scalable manufacturing methods, transitioning from lab research to large-scale production remains challenging, with obstacles including scalable deposition techniques and minimizing material waste. A fully scalable roll-to-roll printing process has been developed to produce lightweight, flexible perovskite solar modules, offering high power density in low-light environments and extended lifetimes, particularly suited for IoT applications requiring long-term autonomous operation.
Path to Commercializating Roll-to-roll Lightweight Flexible Perovskite Solar Modules.
4:10 PM
TNO partner in Solliance
Pioneering Perovskite Scalability: Advancing Roll-to-Roll Slot Die Coating for Stable and Efficient Flexible Solar Cells
4:30 PM
Anuja Vijayan
The rapid advancement of perovskite solar cells (PSCs) over the past decade has positioned them as one of the most promising photovoltaic technologies in the future.1-2 Their unique properties, including high power conversion efficiencies (PCE), tunable optical properties and low-temperature processability, have opened up new avenues for lightweight, flexible and cost- effective solutions for solar energy capture. 3 Achieving this requires a scalable manufacturing process that ensures device efficiency, operational stability, and environmental sustainability.4 At TNO Solliance, we are developing roll-to-roll compatible processes, such as slot die coating using green solvents and ambient processing conditions, to enable low-cost, high-throughput manufacturing.
To address the associated challenges with scalability, we conducted roll-to-roll (R2R) coating experiments on 30 cm wide flexible substrates at a web speed of 3 m/min, focusing on optimizing drying conditions to enhance efficiency. We developed both opaque and semi- transparent flexible p-i-n perovskite devices, achieving power conversion efficiencies (PCEs) of up to 13% using roll-to-roll (R2R) compatible fabrication methods on polymer based substrates. Thermal stress test (85 °C) confirmed initial stability after 1000 hours of continuous exposure. Additionally, we have explored different hole transport layers (HTL) tailored for R2R processing using non-toxic solvents and also investigated how variations in parameters impact performance, stability and reproducibility.
Our approaches are also utilized in flexible metal foils, which offer several advantages, such as mechanical flexibility, lightweight design, cost-effectiveness, and durability. Devices processed via sheet-to-sheet (S2S) level on 15 × 15 cm2 flexible metal substrates achieved efficiencies of up to ~15% with reproducibility. Preliminary results from these substrates processed using R2R method further confirm their strong scalability potential. Additionally, S2S processed metal
foils using R2R compatible solvents deposited under ambient conditions showed efficiencies exceeding 15% alongside excellent stability. Long-term stability tests on these substrates, where non-encapsulated foils exhibited thermal stability for over 3000 hours at 85°C and 100°C. Encapsulated devices withstand damp heat test(85°C/85% RH) and light-soaking test with additional applied heat (55°C), maintaining both visual and performance stability for over 3000 hours, demonstrating robust, non-degrading perovskite architecture.
To further enhance the scalability and product adaptability our approach supports mass customization through modular solar cell semi-fabricates. Using a combination of R2R techniques and automated pick and place systems, individual cells can be tailored and assembled flexibily either at the production site or final installation point. This enables on- demand design for various applications from infrastructure integration to consumer electronics. Our recent R2R development work has demonstrated promising stability and performance metrics in various configurations. By systematically tuning the coating parameters and
exploring a range of stack designs, we have optimized uniformity and device reproducibility, enabling the large-scale, commercially viable production of perovskite solar cells.
Pioneering Perovskite Scalability: Advancing Roll-to-Roll Slot Die Coating for Stable and Efficient Flexible Solar Cells
4:30 PM
Heliatek
Certified, flexible and lightweight PV modules on a commercial scale
4:50 PM
Dr. Andre Weiß
We will be presenting our latest product series, which is the first commercial lightweight and flexible OPV module ever to be certified to IEC 61215. We will also be providing an update on the opportunity to introduce perovskite-containing stacks into existing pilot and production lines originally designed for OPV. The experience we have gained in the vacuum deposition of organic multilayer systems and in encapsulation technologies suitable for roll-to-roll processes has proven to be of great benefit. We will highlight both known and new requirements and pitfalls involved in developing processes for manufacturing lightweight and flexible perovskite-based PV modules.
Certified, flexible and lightweight PV modules on a commercial scale
4:50 PM
OET Energy Technologies/ Coatema
Scaling Printed Photovoltaics: From 3rd Gen PV Innovation to Giga Fab
Industrialization
5:10 PM
The transition from laboratory-scale 3rd Gen PV innovations to large-scale industrial manufacturing represents a defining shift in the evolution of renewable energy technologies. This presentation outlines the pioneering work of OET and the Flex2Energy initiative in establishing the first-ever Giga Fab dedicated to the automated production of printed photovoltaics. Leveraging advanced Roll-to-Roll (R2R) printing and automated assembly, the Automated Manufacturing Line integrates real-time quality control via in-line metrology, AI-driven analytics, and Industry 4.0 frameworks to enable scalable, cost-effective, and sustainable production. OET focuses on delivering customized Integrated Organic Photovoltaic (OPV) solutions for a wide range of applications, including Building-Integrated PVs (BIPVs), Agricultural PVs (AgriPVs), and Vehicle-Integrated PVs (VIPVs), offering flexible, lightweight, and visually adaptive semitransparent solar modules. These solutions aim to harmonize energy generation with the built environment and agriculture, minimizing land use while maximizing energy output. This talk highlights how the merging of advanced materials, digital manufacturing, and intelligent automation positions printed photovoltaics at the forefront of the clean energy transition. The presentation will demonstrate the critical role of scalable OPV and PPV solutions in achieving global net-zero goals.
Scaling Printed Photovoltaics: From 3rd Gen PV Innovation to Giga Fab
Industrialization
5:10 PM
Drinks Reception
Drinks Reception
5:30 PM
Drinks Reception
5:30 PM
There are no more presentations in this track today.
Track 1
Track 2
Track 3
Track 4
Keynotes Track 1 - Estrel Hall A
Sofab Inks
Blake Martin
Novel materials for next-generation perovskite solar panel production processes
2:05 PM
More
As the solar industry pushes toward large-scale production, both efficiency and scalable manufacturing must be prioritized. However, the current challenge lies in identifying materials that not only perform well but also scale effectively for mass production. This talk will explore certain materials that can bridge this gap, offering a solution that balances performance and manufacturability, and addressing key material challenges for perovskite solar cells at scale using soluble processes
Karlsruhe Institute of Technology
Norbert Willenbacher
New Materials for Metallization and Interconnection of Perovskite Cells: Low-Temperature Processing & Reduced Silver Consumption
2:25 PM
More
The goal of significantly reducing CO2 emissions requires a massive expansion of PV installations worldwide. Perovskite cells offer a unique opportunity to enable this at a low consumption of precious resources and energy. This requires metallization and interconnection materials that can be processed at low temperatures. In order to avoid bottlenecks in the supply of silver for contacting and inter-connection of solar cells, the specific silver consumption in the production of solar cells and PV modules must be constantly reduced. The capillary suspension phenomenon (Koos and Willenbacher, Science 331, 897 2011) provides a unique opportunity to design printable pastes and adhesives with high electrical conductivity at low silver consumption. The addition of a second immiscible liquid to a suspension of particles leads to the self-assembly of a strong particle network controlled by capillary forces in such ternary solid/fluid/fluid systems. This results in a drastic change of texture and flow behavior, but also reduces the percolation threshold leading to a high electrical conductivity at low volumetric particle loading in composites including conductive fillers such as silver particles. Pastes for the metallization of temperature-sensitive Perovskite solar cells are sintered at low temperature (< 150°C) and include polymeric additives to provide cohesion of printed finger lines and sufficient adhesion to the transparent conductive oxide (TCO) surface layer. The required polymer content can be reduced and the surface properties of the conductive particles in the contact areas can be designed in such a way that high electrical conductivity and low contact resistance are achieved.
The TECC wire concept uses round copper wires for cell interconnection. These wires are coated with a thermoplastic polymer filled with conductive particles. The polymer ensures good mechanical adhesion to the cell surface and the conductive particles enable low contact resistance. Good interconnection at gentle processing conditions in terms of pressure and temperature has been achieved using thermoplastics with low silver content. Thermoplastic busbars (patent pending) is a recently developed concept further simplifying cell interconnection and reducing resource usage. Electrically conductive, thermoplastic materials melting at low temperature are applied in the metallization process and untreated copper wires are applied in a fast, low temperature stringing process. The capillary suspension concept has been utilized first to design printable, electrically conductive materials including silver particles but the transfer of the concept to composites including other conductive particles such as copper and silver coated copper or glass particles is straight forward.
Nano-C, Inc.
Henning Richter
Innovative Interface Materials for Perovskite Photovoltaics
2:45 PM
More
Suitable interface materials are highly critical for single-junction but also tandem Perovskite photovoltaics both in terms of power conversion efficiency and, particularly, stability. Using its long experience with fullerenes and fullerene derivatives addressing improved performance of organic photovoltaic devices as starting point, Nano-C has developed a range of new generation electron transporting interface materials allowing for passivation and prevention of delamination. C60 or C70 fullerenes bearing suitable functional groups such as phosphonic, carboxylic or ammonium chloride/iodide allow for the stabilization of the Perovskite phase and adhesion on the adjacent metal oxide layers. Electronic properties can be adjusted for optimized band alignment depending on the specific Perovskite phase used. Molecules synthesized by Nano-C will be described and use cases discussed. The industrial scale manufacturing of fullerenes and new generation fullerene derivatives intended to accelerate the commercial deployment of Perovskite technology will be presented.
DELO Industrial Adhesives
Sebastian Stasch
Pioneering the Future: DELO's Advanced Adhesives Enhance Perovskite Solar Cell Protection
3:05 PM
More
High-barrier encapsulants are essential for the protection of perovskite solar cells, acting as a shield against moisture that can cause degradation. These encapsulants create a strong, flexible seal that enhances the cells' durability, longevity, and efficiency. DELO, renowned for its barrier adhesives in organic solar cells, is leveraging its expertise to develop new adhesive solutions specifically designed for perovskite solar cells. This talk will provide insights into DELO's current advancements in this field, highlighting how these new adhesives are tailored to meet the unique challenges of perovskite technology, ensuring improved stability and performance.
Break
--------------------------------
Exhibition & Refreshment Break
3:25 PM
More
Drinks Reception
5:30pm
